12 www.pridemobility.com Jazzy 1400/Rev C/Sept02
Specifications
Suspension: Full suspension with Active-Trac
Rear Suspension
Drive Wheels: 36 cm (14 in.), pneumatic (solid tyres are optional)
Casters Wheels: 20 cm (8 in.), solid, rear articulating
Anti-tip Wheels: 15 cm (6 in.), solid, front mounted
Maximum Speed: 7.2 km/h (4.5 mph)
Brakes: “Intelligent Braking,” electronic regenerative, disc park brake
Ground Clearance: 7.5 cm (3 in.)
Turning Radius: 54.5 cm (21.5 in.)
Overall Size: Length: 103 cm (40.5 in.)
Width: 65 cm (25.4 in.)
Seating Options: Euro Seat
Versa Tilt
Medium-Back Seat
High-Back Seat
Reclining Seat
Power Elevating Option
Drivetrain: Two motor, mid-wheel
Batteries: Two 12-volt, Group 24 batteries (NF-22 batteries for the power
seat option)
Range: Up to 40 km (25 miles)
Battery Charger: 5-amp Onboard
5-amp off-board (optional)
Electronics: 70-amp P & G Remote Plus Controller
70-amp Dynamic Europa Remote Controller
Weight Capacity: 180 kg/400 lbs./28 Stone
(146 kg/325 lbs./23 Stone w/hi-speed motors)
Component Weights: Base: 58 kg (128 lbs.)
Seat: 20 kg (29 lbs.)
Batteries: 24 kg (53.5 lbs. each
Warranty: Lifetime limited warranty on frame
Two-year warranty on electronics
Eighteen-month warranty on drive motors
I V . T H E J A Z Z Y 1 4 0 0
