Wall Mounting
86
To remove the wall mounting adaptor
While pushing down the RELEASE LEVERS ( A), remove the adaptor (B).
Charger unit (KX-TG6502 only)
The charger can be wall mounted. Connect the AC adaptor. Install screws using the
wall template (see below). Mount the charger (
A ). Slide it down ( B ), then slide
down to the right ( C ) until it is secured.
2
1
1
RELEASE
LEVERS
A
B
C
Screws
To Power
Outlet
2.45 cm
( 31 ⁄
32
")
2.45 cm
(
31 ⁄
32
")
Wall Template for the Charger unit
