Philips Semiconductors
TDA9964
12-bit, 3.0 V, 30 Msps analog-to-digital interface for CCD cameras
Objective specification Rev. 03 — 16 January 2001 2 of 23
9397 750 07918 © Philips Electronics N.V. 2001. All rights reserved.
4. Quick reference data
5. Ordering information
Table 1: Quick reference data
Symbol Parameter Conditions Min Typ Max Unit
V
CCA
analog supply voltage 2.7 3.0 3.6 V
V
CCD
digital supply voltage 2.7 3.0 3.6 V
V
CCO
digital outputs supply voltage 2.5 2.7 3.6 V
I
CCA
analog supply current all clamps active
−
60
−
mA
I
CCD
digital supply current
−
3
−
mA
I
CCO
digital outputs supply current f
pix
= 30 MHz; C
L
= 10 pF; input ramp
response time is 800
µ
s
−
1
−
mA
ADC
res
ADC resolution
−
12
−
bits
V
i(CDS)(p-p)
maximum CDS input voltage
(peak-to-peak value) V
CC
= 2.85 V 650
− −
mV
V
CC
≥
3.0 V 800
− −
mV
f
pix(max)
maximum pixel frequency 30
− −
MHz
f
pix(min)
minimum pixel frequency tbf
− −
MHz
DR
PGA
PGA dynamic range
−
24
−
dB
N
tot(rms)
total noise from CDS input to
ADC output PGA gain = 0 dB; see Figure 8
−
1.5
−
LSB
E
in(rms)
equivalent input noise (RMS
value) gain = 24 dB
−
70
− µ
V
P
tot
total power consumption V
CCA
= V
CCD
= V
CCO
= 3 V
−
195
−
mW
V
CCA
= V
CCD
= V
CCO
= 2.7 V
−
175
−
mW
Table 2: Ordering information
Type number Package
Name Description Version
TDA9964HL LQFP48 plastic low profile quad flat package; 48 leads; body 7
Ч
7
Ч
1.4 mm SOT313-2
