APPENDIX C
FACTORY REPLACEMENT PARTS
AND ACCESSORIES
Patton Model #
Description
10-2500 ...........................DDS Cable, RJ48 - RJ48, 6 foot
10-561S...........................Control Port Cable, EIA-561, 6ft, shielded
12M-561 ..........................Adapter, EIA-561 to DB-25 Male
12F-561 ...........................Adapter, EIA-561 to DB-25 Female
082R2..............................Fuse 5x20mm, 200mA, 250V, Time-lag
Little Fuse P/N 239.200
0805US ...........................American Power Cord
0805EUR.........................European Power Cord CEE 7
0805EURP ......................Europlug Power Cord CEE 7/16
0805UK ...........................United Kingdom Power Cord
0805AUS .........................Australia/New Zealand Power Cord
0805DEN.........................Denmark Power Cord
0805FR............................France/Belgium Power Cord
0805IN.............................India Power Cord
0805IS .............................Israel Power Cord
0805JAP ..........................Japan Power Cord
0805SW...........................Switzerland Power Cord
APPENDIX D
INTERFACE PIN ASSIGNMENT
DDS INTERFACE
The DDS Interface is an RJ-48S modular jack.
Pin #
Signal
1
TX+
2
TX-
3
no connection
4
no connection
5
no connection
6
no connection
7
RX+
8
RX-
M/34 CONNECTOR, TERMINAL INTERFACE
Pin #
Signal
B
SGND (Signal Ground)
C
RTS
D
CTS
E
DSR
F
CD
H
DTR
L
LL (Local Loop)
M
TM (Test Mode)
N
RL (Remote Loop)
P
TD
R
RD
S
TD/
T
RD/
U
XTC
V
RC
W
XTC/
X
RC/
Y
TC
AA
TC/
