Controls the 1/4" jack input level on channels 1 and 2 and the 1/4" jack input and XLR input on channel 3.
((2
2)) LLo
ow
w E
EQ
Q
An active tone control (shelving type: +/-15 dB) that varies the low frequency range.
C
C a
a u
u tt ii o
o n
n :: Excessive low frequency boost causes greater power consumption and increases the
possibility of speaker damage.
((3
3)) H
Hii E
EQ
Q
An active tone control (shelving type: ± 15 dB) that varies the hi frequency range.
((4
4)) M
Miid
d E
EQ
Q
An active tone control (peak/notch type: ± 15dB) that varies the mid frequencies. (channel 3)
((5
5)) C
CH
H4
4//M
Mo
on
niitto
orr LLe
evve
ell
Controls the input level for channel 4. Controls high-impedance microphones or other high-level sources
equipped with a 1/4" phone plug.
((6
6)) H
He
ea
ad
dp
ph
ho
on
ne
e LLe
evve
ell ((K
KB
B3
3 o
on
nlly
y))
This sets the level to the headphone jack on the rear panel. To avoid damage to your hearing‚ make sure
to turn the dial fully counter-clockwise before using headphones. Slowly turn the knob clockwise until a
comfortable listening level is set. This does not affect the master level.
((7
7)) M
Ma
asstte
err LLe
evve
ell ((K
KB
B3
3 o
on
nlly
y))
This knob sets the overall level for the unit. Make sure the Master level is completely down (full counter-
clockwise) before powering up the unit. This does not affect the headphone level.
((8
8)) P
Po
ow
we
err S
Sw
wiittcch
h
This two-way rocker switch applies power to the unit when placed in the ON position.
