Figure 7 – ParaBody 880 User Manual
Page 9
STEP 7:
FIGURE 7
• Route the SHORT LEG PRESS CABLE (2) through the PULLEY PLATES as shown in FIGURE 7.
3/8 X 1-3/4” 7
• Route the SHORT LEG PRESS CABLE (2) around one 3-1/2” PULLEY (4) and assemble the PULLEY to the PULLEY BRACKET
(15) using one 3/8 X 1-3/4” BOLT (7) and one previously removed 3/8” LOCK NUT. See FIGURE 7.(Note: Loop the SHORT
LEG CABLE (2) around the PULLEY prior to assembling the PULLEY to the PULLEY BRACKET.)
9
4
15
3/8” LOCK NUT
PULLEY
PLATES
2
