Figure 12, Cable routing diagram – ParaBody 880 User Manual
Page 25
FIGURE 12
STEP 12:
3/8 X 4-1/2” 10
3
12
13
SEAT FRAME
14
25
• SECURELY assemble the threaded end of the LONG LEG PRESS CABLE (3) to the SEAT FRAME using one 3/8 X 4-1/2”
BOLT (10), two 3/8 X 1” SPACERS (13), one previosly removed THREADED HOUSING, two 3/8” FLANGE SPACERS (14)
and one 3/8”LOW HEIGHT LOCK NUT (12).
CABLE ROUTING DIAGRAM
3/8” LOW HEIGHT
LOCK NUT
THREADED
HOUSING
