11
English
Preparations
Rear connections
The type plate is located at the rear of the
system.
A Power
Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
WARNING!
– For optimal performance, use only the
original power cable.
– Never make or change any connections
with the power switched on.
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
B Antenna Connection
AM Antenna
Connect the supplied AM loop antenna to the
“AM aerial” terminal. Adjust the position of the
antenna for optimal reception.
●
Position the antenna as far as possible from a TV,
VCR or other radiation source.
MW
speaker
(right)
speaker
(left)
FM wire antenna
F M
A E R I A L
A M A E R I A L
AM loop
antenna
AC power cord
n
