PT191MU User’s Guide (020-0418-00 B)

13

User Controls

Front Panel Controls

Select/Auto

To pop up the OSD menus.

Select- To select the adjust ment
items from OSD menus.
Auto- To activate the “Auto
Adjustment” function to obtain
an optimum image.

1. Decreases the brightness of
the display image.
2. Decreases value of the
adjustment items.

1. Increases the brightness of
the display image.
2. Increases value of the
adjustment items.

1. Green indicates the display is
turned on.
2. Amber indicates the display
in power-saving mode.

Switches on/off the power of the
LCD display.

Brightness Minus/Minus

Brightness Plus/Plus

Power Switch

Power LED

Menu button

SELECT/AUTO

MENU
