Start Your Installation
• Connecting the display (Figure 1.1)
To setup this display, please refer to the following fi gure and procedures.
1. Be sure all equipment is off .
2. Connect the DC power cord to the power connector. Plug one end of the
AC power cord into the power adapter, and the other end into an electrical
outlet(1).
3. For the PC with Analog output: connect the VGA signal cable from display
VGA input connector to the 15-pin connector of your host computer and
tighten the screws(2).
4. For the PC with DVI digital output: Connect the DVI signal cable to the
connector of the display card in your computer; connect the other side to
the DVI-D input port of your display. Tighten the screws(3).
5. Connect the Audio-In cable from audio input port of your display to the
Audio-out port of your computer(4).
6. Connect the USB cable from USB port of your display to the USB port of
your computer(5).
7. Confi gure the touchscreen. Refer to the “Touch Screen Driver Installation”
section on page 23.
8. Once the touchscreen is confi gured, turn on your computer, display and
video source.
Notice: To ensure the LCD display works well with your computer, please
confi gure the display mode of your graphic card to make it less than
or equal to 1280 x 1024 resolution and make sure timing of the display
mode is compatible with the LCD display. We have listed the “Compat-
ibility Modes” of this LCD display in appendices for your reference.
