8
STEP 4:
FIGURE 4
0 1 2 3 4 5 6
1/2 1/2 1/2 1/2 1/2 1/2
• Insert one 1-3/4” ROUND END CAP (20) into the end of each HOUSING (6) as shown in FIGURE 4.
• Slide one 2-1/2” OD BUMPER (19) over the end of each HOUSING (6) as shown in FIGURE 4.
• Insert the shaft of the HOUSINGS (6) into the ends of the SMITH BAR (5) as shown in FIGURE 4.
5
6
19
20
REMOVE PLASTIC INSERTS!
!! IMPORTANT !!
PLEASE REMOVE THE TAPE AND PLASTIC TUBE FROM BOTH OF THE
HOUSINGS AS SHOWN!
HOUSING
