ParaBody 888 - Manual (Page 5)

5
PARTS LIST
PART #
6805608
6805708
6798502
6798402
6799702
6801301
6799601
6799208
6799801
6714901
3239001
KEY
1
2
3
4
5
6
7
8
9
10
11
QTY
1
1
1
1
1
2
2
1
2
4
2
PART #
6692601
3102910
3102502
3102801
3105302
3105303
6824601
6695801
3119302
6807101
7183508
DESCRIPTION
3 X 2” END CAP
1/2 X 3 BOLT
1/2” WASHER
1/2” LOCK NUT
7/16” HOLE PLUG
9/16” HOLE PLUG
3-1/4 X 1-3/4” GLIDE
2 1/2” OD RUBBER BUMPER
1-3/4” ROUND END CAP
GUN RACK
UPRIGHT FRAME RIGHT
QTY
2
12
6
12
8
16
6
2
4
2
1
DESCRIPTION
UPPER CROSS BRACE
LOWER CROSS BRACE
SAFETY STOP LEFT
SAFETY STOP RIGHT
SMITH BAR
HOUSING
PLATE HOLDER
UPRIGHT FRAME LEFT
72” GUIDE ROD
GUIDE ROD BUSHING
1” SHAFT COLLAR
KEY
12
13
14
15
16
17
18
19
20
21
22
FIGURE 1
STEP 1:
• Insert two 1-3/4” ROUND END CAPS (20) into the end of the PLATE HOLDERS (7) as shown in FIGURE 1.
7
20
