Peavey Supreme - Manual (Page 6)

Rated Power Load:
Power specs measured with
T. Dynamics 10%
100 W RMS into 16, 8, or
4 ohms
Power Clipping: (typically)
(5% THD, 1 120 V AC line)
W RMS into 16, 8, or
4 ohms
Frequency Response:
3 60 Hz to 20
Hum Noise:
Greater than 86 below rated
power
Power Consumption:
Domestic: 300 W 60 Hz,
120 VAC
Export: 300 W Hz,
V AC
PREAMP SECTION
The following specs are measured
I with the controls preset as follows:
Push Bright, Off (out)
Channel Select Normal (out)
High 10
Mid 0
Presence 0
Pre Post Gain 10
Gain Thrash, Off (out)
Normal Levels are with normal volume
Minimum Levels are with normal
volume
SPECIFICATIONS
Preamp High Gain Input:
Impedance: High-Z, 1 M ohm
Nominal Input Level: -14
200 RMS
Minimum Input Level: -24
60 RMS
Maximum Input Level: 0
1 VRMS
Preamp Low Gain Input:
Impedance: High-Z, 44 K ohms
Nominal Input Level: -8
400 RMS
Minimum Input Level: -18
120 RMS
Maximum Input Level: 6
2 V R M S
Effects Send:
Load Impedance: 1 K ohm or
greater
Nominal Output Level: -10
0.3 V RMS or 0 1 V RMS
if Effects Level is in
Effects Return:
Impedance: High-Z, 22 K ohms
Designed Input Level: -10
0.3 V RMS or 0 1 V RMS
if Effects Level is in
(Switching jack provides Effects Send to
Effects Return connection when not used)
Preamp Output:
Load Impedance: 1 K ohm or
greater
Nominal Output Level: 0
1 VRMS
Power Amp Input:
Impedance: High-Z, 30 K ohms
Designed Input Level: 0
1 VRMS
(Switching jack provides preamp output to
power amp input connection when not
used)
System Hum Noise
Nominal Input Level:
(20 Hz to 20 weigh ted)
72 below rated power
Equalization:
Special low, mid, high passive
Presence: 5
Push Bright: 2
Push Thrash: -20 notch
1 in Lead channel
Push Gain: Increases Lead gain
Push Resonance:
cabinet resonance
External Footswitch Functions:
Lead Channel Defeat (when
selected with button)
Effects Loop Bypass
Dimensions Weight:
10.25” H x 24.375” W x D
35.7 Ibs.
A
Due to our for constant improvements,
features and listed herein are subject to change without notice.
