35
● Camera Display Position
This item lets you select the position where the camera
images will be displayed on the multiscreen 2 monitor.
1. Move the cursor to DISPLAY POSITION, then press the
[HOME/SET] button.
The table shown in the figure appears on the monitor.
2. Move the cursor to the desired channel number by
pressing the C or D button.
3. Select the numbers of the cameras to be displayed by
pressing the A or B button.
The images of the selected cameras are displayed one
after another on the monitor screen.
Note: Numbers can also be input directly with the
Camera Number buttons (1 - 10).
4. After completing the setting, press the [SET UP/ESC]
button to return to the previous MULTI 2 OUTPUT
SETUP menu.
Note: This operation only affects the camera display
positions.
It has no effect on the camera channel, recording
order or sequence order.
● Sequence Mode
This item lets you select the sequence pattern for display
on the multiscreen 2 monitor.
Refer to Sequence Setup on page 37 for more details.
1. Move the cursor to the SEQUENCE MODE parameter.
2. Select the desired sequence mode.
SEQ1: Spot Sequence
SEQ2: Multi Sequence
SEQ3: Multi Sequence
The factory default setting is SEQ2.
3. After finishing the setting, press the [SET UP/ESC] but-
ton to return to the previous SETUP MENU.
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
