Poulan 532175732 User Manual
Page 9
9
WA
RN
ING
Do
no
t o
pe
rat
e m
ow
er
un
les
s c
on
tai
ne
r is
pro
pe
rly
is
su
bje
ct
to
we
ar
an
d d
eti
eri
ora
tio
n.
Ch
eck
ba
g f
req
ue
ntl
y. R
ep
lac
e w
he
n
cra
cke
d o
r d
am
ag
ed
. U
se
on
ly a
rec
om
me
nd
ed
rep
lac
em
en
t c
on
tai
ne
r.
WA
RN
IN
G
020
82
CONTAINER MOUNTING (See Fig. 6)
No hardware required
1. Install one container to left side fi rst with warning to
outside of unit. Install other container to right side.
NOTE: Right con tain er should always over lap left con tain er
at center sup port.
2. Close cover and lock latch handle over center support
tube.
6
CENTER
SUPPORT
TUBE
COVER LATCH
HANDLE
CONTAINER
WARNING
CONTAINER
HANDLE
CONTAINER
WARNING
FIG. 6
7
CAUTION: Do not remove discharge
guard from mower. Raise and hold guard
when attaching lower chute and allow it
to rest on chute while in operation.
LOWER CHUTE (See Figs. 7A & 7B)
Use Hardware - - GROUP "D"
1. Press weld nut into rubber latch and install two latch
hook assemblies to lower chute using screw, fl at washer,
and lock washer as shown.
2. Tighten hardware securely.
3. Raise and hold defl ector shield in upright position.
4. Place front of chute over front of mower deck opening
and slide into place as shown.
5. Hook front latch down into latch hole at front of mower
deck.
6. Hook rear latch down into latch hole at back of mower
deck.
02
475
FIG. 7A
WELD NUT
FIG. 7B
024
76
SCREW
LATCH
WASHER
LOCK
WASHER
WELD NUT
LATCH
DEFLECTOR
SHIELD
LATCH
HOOKS
WASHER
LOCK
WASHER
