Panasonic EY6450 - Manual (Page 8)

- 8 -
. LAMP INDICATIONS LAMP INDICATIONS
Red Flashing
Red Lit
Green Flashing quickly
Orange Lit
Orange Flashing
Charger is plugged into the AC outlet.
Ready to charge.
Now charging
Charging is completed.
Battery pack is warm. Charging will begin
when temperature of battery pack drops.
Charging is not possible. Clogged with
dust or malfunction of the battery pack.
. ACCESSORIES ACCESSORIES
Use only bits suitable for size of drill’s chuck.
MAXIMUM RECOMMENDED CAPACITIES
EY6450 MATERIAL / CONDITION SPEED
Screw
driving
Wood screw ø 4.2 mm (3/16") ± 75 mm (3") HIGH
Self-drilling screw ø 3 mm (1/8") ± 13 mm (1/2") SPC t = 1.6 mm (1/16") HIGH
Drilling
Wood ø 50 mm (2") Yellow pine t = 38 mm (1-1/2") LOW
Metal ø 13 mm (1/2") SPC t = 1.6 mm (1/16") HIGH
. SPECIFICATIONS SPECIFICATIONS
MAIN UNIT
Model EY6450
Motor DC Motor 18 V
No load speed
LOW 70 ~ 430 /min (rpm)
HIGH 240 ~ 1500 /min (rpm)
Chuck capacity ш 0.5 ~ ш 13 mm (0 ~ 1/2")
Maximum stalling
torque
LOW 36 Nm, (367 k f-cm, 319 in-lbs)
HIGH 9.5 Nm, (97 k f-cm, 84 in-lbs)
Cluch stage
Stage1-15
Approx. 2 Nm, (20 k f-cm or 18 in-lbs)~
12 Nm, (122 k f-cm or 106 in-lbs)
For powerful driving and drilling.
Overall length 250 mm (9-13/16")
Weight (with battery pack) 2.6 k , (5.7 lbs)
BATTERY PACK
Model EY9251
Storage battery Ni-MH Battery
Battery voltage 18V DC (1.2V × 15 cells)
