44
Setup menus
VIDEO
Item Setting
No.
Superimposed
display
No.
Superimposed
display
Description of settings
“ ” indicates the factory setting.
630 1080i >HD_OUT
0000
0001 1080i
720p
For selecting the HD output signal format during 1080i tape playback or in the
1080i EE mode.
0: 1080i
1: 720p
O This item’s setting cannot be changed while a tape is being recorded or while
the recording pause mode is established.
O When 720p is selected as this item’s setting, no signals are output from the DV
connector. If “1394” is selected as the menu item No.600 [VIDEO IN SEL]
setting, “HDSDI” is established as the VIDEO IN SEL setting.
632 720p >HD_OUT
0000
0001 1080i
720p
For selecting the HD output signal format during 720p tape playback or in the 720p
EE mode.
0: 1080i
1: 720p
O This item’s setting cannot be changed while a tape is being recorded or while
the recording pause mode is established.
O When 1080i is selected as this item’s setting, no signals are output from the DV
connector. If “1394” is selected as the menu item No.600 [VIDEO IN SEL]
setting, “HDSDI” is established as the VIDEO IN SEL setting.
634 480p >HD_OUT
0000
0001 1080i
720p
For selecting the HD output signal format during 480p tape (DVCPRO50P)
playback.
0: 1080i
1: 720p
636 480i >HD_OUT
0000
0001 1080i
720p
For selecting the HD output signal format during 480i tape (DVCPRO50, DVCPRO,
DV or DVCAM) playback.
0: 1080i
1: 720p
676 BLK CLIP
0000
0001 OFF
ON
For setting whether to clip what is below the pedestal level for the Y (luminance)
signal of VIDEO OUT and SD OUT.
0: What is below the pedestal level is not clipped.
1: What is below the pedestal level is clipped.
628 U/C ENH H
0000
0001 0dB
+1dB
For enhancing the horizontal outlines during up-conversion.
0: 0dB
1: +1dB
629 U/C ENH V
0000
0001 0dB
+1dB
For enhancing the vertical outlines during up-conversion.
0: 0dB
1: +1dB
626 D/C ENH H
0000
0001 0dB
+1dB
For enhancing the horizontal outlines during down-conversion.
0: 0dB
1: +1dB
627 D/C ENH V
0000
0001 0dB
+1dB
For enhancing the vertical outlines during down-conversion.
0: 0dB
1: +1dB
621 UPCON V MODE
0000
0001
0002 FIT_V
FIT_H
FIT_HV
For setting the image processing during up-conversion.
0: Side panel mode
1: Top and bottom cut-off in vertical direction
2: Stretch mode
