ACCESSORIES
Use only bits suitable for size of drill’s chuck.
Use Panasonic original Optional Keyless drill chuck (EY9X003E) and Quick change chuck (EY9HX110
E)
for maximum performance.
SPECIFICATIONS
MAIN UNIT
KEYLESS DRILL CHUCK
BATTERY PACK
BATTERY CHARGER
Note: This chart may include models that are not available in your area.
Please refer to the catalogue.
CAUTION: This Panasonic Multi Drill & Driver is designed to use only battery pack type EY9230,
EY9136. Use with other battery pack type may damage the tool and the battery, and may
result in the risk of fire and personal injury.
Model
EY6535
Drill driver Mode
Impact mode
(Caution: Do not use Keyless drill chuck for impact mode)
Maximun
recommen
ded
capacities
Drilling
Wood drilling
ø 27 mm (1 - 1/16")
Not feasible
Metal drilling
ø 13 mm (1/2")
Screw
driving
Machine screw
M5
Not feasible
Wood screw
ø 6.8 mm (17/64")
Tech screw
ø 6 mm (15/64")
Coach screw (Lag bolt)
ø10 mm (3/8")
Bolt Fastening
Not feasible
Standard Bolt: M12
High Tensile Bolt: M10
No load speed
0 - 650 /min (rpm)
0 - 2200 /min (rpm)
Clutch Torque
Approx.
1.0 Nm (10 kgf-cm, 8.7 in-lbs.) -
5.4 Nm (55 kgf-cm, 47.7 in-lbs.)
-
Impact per minute
-
0 - 3300 /min (ipm)
Motor
DC Motor 15.6V
Square drive
12.7 mm (1/2") square drive with ball detent
Weight (with battery pack)
2.2 kg ( 4.8 lbs.)
Overall length
216 mm ( 8 - 1/2")
Model
EY9X003E
Chuck Capacity
1.6 mm - 13 mm (1/16" - 1/2")
Model
EY9230
Storage battery
Ni-MH Battery
Battery voltage
15.6V DC (1.2V x 13 cells)
Model
EY0230
Electrical Rating
See the name plate on the bottom of the charger.
Weight
0.78 kg (1.72 lbs)
Charging time
15.6 V
12 V
9.6 V
7.2 V
Standard charging time
-
EY9001
EY9006
EY9080
EY9086
EY9065
EY9066
Approx. 20 min.
-
EY9101
EY9103
EY9180
EY9182
-
Approx. 25 min.
EY9136
EY9106
EY9107
EY9108
-
EY9168
Approx. 30 min.
EY9230
EY9200
-
-
Approx. 45 min.
