17
Item Standards Resolution
Dot Clock
(MHz)
Vertical
Scanning
Frequency
(Hz)
Horizontal
Scanning
Frequency
(kHz)
Sync Polarity or
composite sync
(H/V)
Operating
Mode
28 VESA 1280x960 108.0 60.0 60.0 +/+ A/D
29 VESA 1280x1024 108.0 60.02 63.98 +/+ A/D
30 VESA 1280x1024 127.0 69.85 74.88 +/+ A/D
31 VESA 1280x1024 135.0 75.03 79.98 +/+ A/D
32 SUN 1024x768 64.13 59.98 48.29 H+V A
33 SUN 1024x768 74.25 70.04 56.59 H+V A
34 SUN 1024x768 84.38 77.07 62.04 H+V A
35 SUN 1280x1024 117.0 67.19 71.69 H+V A
36 SUN 1280x1024 135.0 76.10 81.13 H+V A
37 VESA 1600x1200 162.0 60.00 75.00 +/+ A/D
*A=Analog Mode; D=Digital Mode
*Once a mode is optimized, there is no need to make any further adjustment as long as
the VGA card remains unchanged.
*Specifications are subject to change without notice.
