16
A
PPENDIX
B
Supported Timing
Timing for Model FMT2315U (UXGA Resolution)
Ite
m
Standards Resolution
Dot
Clock
(MHz)
Vertical
Scanning
Frequency
(Hz)
Horizontal
Scanning
Frequency
(kHz)
Sync
Polarity or
composite
sync (H/V)
Operating
Mode
1 NEC PC98 640x400 25.20 70.15 31.50 -/- A
2 NEC PC98 640x400 21.05 56.42 24.83 -/- A
3 MAC 13”
mode
640x480 30.24 66.67 35.00 -/- A/D
4 MAC 16”
mode
832x624 57.28 74.55 49.73 -/- A/D
5 MAC 17”
mode
1024x768 80.00 75.02 60.24 -/- A/D
6 VGA 640x350 25.18 70.09 31.47 +/- A/D
7 VESA 640x350 31.50 85.08 37.86 +/- A/D
8 VGA 640x400 25.18 70.09 31.47 -/+ A
9 VESA 640x400 31.50 85.08 37.86 -/+ A
10 VGA 640x480 25.18 59.94 31.47 -/- A/D
11 VESA 640x480 31.50 72.81 37.86 -/- A/D
12 VESA 640x480 31.50 75.00 37.50 -/- A/D
13 VESA 640x480 36.00 85.01 43.27 -/- A/D
14 VESA 800x600 36.00 56.25 35.16 +/+ A/D
15 SVGA 800x600 40.00 60.32 37.88 +/+ A/D
16 VESA 800x600 50.00 72.19 48.08 +/+ A/D
17 VESA 800x600 49.50 75.00 46.88 +/+ A/D
18 VESA 800x600 56.25 85.06 53.67 +/+ A
19 VGA 720x400 28.32 70.09 31.47 -/+ A
20 VESA 720x400 35.50 85.04 37.93 -/+ A/D
21 XGA 1024x768 65.00 60.00 48.36 -/- A/D
22 VESA 1024x768 75.00 70.07 56.48 -/- A/D
23 VESA 1024x768 78.75 75.03 60.02 +/+ A/D
24 1024x768 71.64 66.13 53.96 +/+ A/D
25 VESA 1152x864 108.0 75.00 67.50 +/+ A/D
26 VESA 1152x864 121.5 85.00 77.09 +/+ A/D
27 VESA 1024x768 94.50 85.00 68.68 +/+ A/D
