TECHNICAL SPECIFICATIONS
ADDITIONAL PRODUCT FEATURES
• Deterrent Surveillance
• Integral Multiprotocol (Coaxitron
® , RS-422 Pelco D and Pelco P Protocols)
Receiver/Driver
• Digital Position and Zoom Control and Feedback Using Pelco D Protocol
• Integral Camera Enclosure
• Operational in 145 kph (90 mph) Winds, Can Withstand Wind Velocity up
to 209 kph (130 mph)
• Pan Preset Speed of 100°/Sec in 80 kph (50 mph) Winds and 50°/Sec in
145 kph (90 mph) Winds
• Variable Scan Speeds (1° to 40°/Sec)
• Translator Boards for Selected Competitive Protocols
• Easy to Install: Quick and Simple Electrical Connections
• 24 VAC or 120/230 VAC Selectable
• Full Continuous-Duty Warranty
• 850 nm and 950 nm Active IR Illumination Focus Algorithms
• 256 Configurable Presets with Labels
• Auto, Frame, and Random Scan
• Configurable Power-Up Mode, Park, Manual Limit Stops (Pan), and Scan
Limit Stops (Pan)
• Patterns: Up to 8, On-Screen, User-Defined Configurable Patterns;
Includes Pan, Tilt, Zoom, and Preset Functions
• Proportional Pan/Tilt: Continually Decreases Pan/Tilt Speeds in Proportion
to Depth of Zoom
• 8 Zones (configurable in size) Can Be Labeled with up to 20 Characters
Each
• Window Blanking: Up to 8, Four-Sided, User-Defined Shapes
• 10-Inch Integrated Enclosure with Pre-Assembled IOP Camera
• Sun Shroud, Heater/Window Defroster, and Insulation All Standard
• 1 Auxiliary Output
• Electronic Image Stabilization
• Image Enhancement
• Multilingual Menus (English, Spanish, Portuguese, Italian, French,
German, Russian, Polish, Turkish, Czech, and Asian language package:
Chinese, Japanese, Korean)
• Software Update and Setup
• Configurable Locations of Labels and On-Screen Displays
• Configurable Zoom Speeds
• Low Lux Noise Reduction (reduces noise in low light)
• Autosensing Protocol (Coaxitron
® , RS-422 Pelco P and Pelco D,
Sensormatic ® , Vicon ® ); Accepts Other Control Protocols with Optional
Translator Card
PRESSURIZED INTEGRATED OPTICS CARTRIDGE (IOC)
• Pressurized to 10 psig, Nominal (Sea Level, 21°C [70°F])
• Internal Sensors for Temperature, Dew Point, and Pressure
• On-Screen Alert for High and Low Temperature, High and Low Pressure,
and High Humidity
• 4 Alert On-Screen Display Modes
• 4 Acknowledge Modes
• Pressurized Relief Valve
• Meets IP67 Standards
ELECTRICAL
Input Voltage 24, 120, or 230 VAC, 50/60 Hz; switch
selectable for 120/230 VAC inputs
Input Voltage Range ±10%
Power Consumption Maximum 70 VA per system
Heater and Defroster Thermostatically controlled
Electrical Connections 2 power source connections made at mount
location with wire splices and 1 ground wire
splice; 1 BNC receptacle and 4 wire splices at
mount location for RS-422 Pelco D and Pelco P
protocols; 2 wire splices for open collector
auxiliary output
Aux 2 Open collector output with 2-second
activation; connected relay must require no
more than 32 VDC and 40 mA to energize relay
coil; wire length between Esprit SE and relay
must be less than 30 m (100 ft)
Video Coaxial Cable
Wiring Distances
Cable Type* Maximum Distance
RG59/U 229 m (750 ft)
RG6/U 305 m (1,000 ft)
RG11/U 457 m (1,500 ft)
*Minimum cable requirements: 75-ohms impedance; all copper center
conductor; all copper braided shield with 95% braid coverage.
MECHANICAL
Pan Movement 360° Continuous pan rotation
Vertical Tilt Unobstructed +36° to –85°
Variable Pan/Tilt Speed
Pan 0.1° to 40°/sec variable-speed operation,
100°/sec turbo
Tilt 0.1° to 30°/sec variable-speed operation
Preset Speeds
Pan 100°/sec
Tilt 30°/sec
Camera Mounting Integrated camera sled assembly
Latches One link-lock, No. 3 stainless-steel latch; can
be secured with padlock (not supplied)
GENERAL
Construction Die-cast, extruded and sheet aluminum;
stainless steel hardware
Finish Gray polyester powder coat
Viewing Window 5.84 mm (0.23") thick, optically clear,
polycarbonate with proprietary impact-
resistant UV rated coating
Operating Temperature –45° to 50°C (–50° to 122°F) for sustained
system operation or 60°C (140°F) absolute
maximum; within two hours after power-up,
the entire unit can de-ice and be operational
from a temperature of –25°C (–13°F)
Operating Environment Will remain operational in 145 kph (90 mph)
wind conditions;
withstands 209 kph (130 mph)
Weight With With
Pedestal Adapter Wall Mount
Unit
Standard with IOP 9.0 kg (20 lb) 9.9 kg (22 lb)
With Wiper and IOP 9.5 kg (21 lb) 10.4 kg (23 lb)
Standard with IOC 9.5 kg (21 lb) 10.4 kg (23 lb)
With Wiper and IOC 10.0 kg (22 lb) 11.0 kg (24 lb)
Shipping
Standard with IOP 11.3 kg (25 lb) 12.6 kg (28 lb)
With Wiper and IOP 11.7 kg (26 lb) 13.1 kg (29 lb)
Standard with IOC 11.7 kg (26 lb) 13.1 kg (29 lb)
With Wiper and IOC 12.3 kg (27 lb) 13.6 kg (30 lb)
