Polaris MAGNUM 325 4X4 A00CD32AA - Manual (Page 55)

D13
FUEL PUMP
MAGNUM 325 4X4 A00CD32AA and MAGNUM 325 4X4 A00CD32CA and 325 MAGNUM 4X4 HDS A00CD32FA and 325 MAGNUM 4X4 HDS II A00CD32FB
4
1
3 2
2
4
Ref. Part No. Qty. Description Ref. Part No. Qty. Description
3085275 1 Asm., Fuel Pump (Incl. 1-4)
1 3084999 1 Screw and Washer
2 3085000 2 Screw and Washer
3 3084591 4 Screw
4 3084998 1 Diaphragm Gasket Set
11/98
