B14
DRIVE CLUTCH
MAGNUM 325 4X4 A00CD32AA and MAGNUM 325 4X4 A00CD32CA
14
1
2
13
12
5
11
3 4
5
6
10
9
7
8
Ref. Part No. Qty. Description Ref. Part No. Qty. Description
1 7512176 6 Bolt
2 7552801 6 Washer
3 5430945 6 Washer, Multilube
4 1321457 3 Roller and Bushing
5 5431936 6 Button, Clutch
6 5210752
5242981
5210753
5210754
AR
AR
AR
AR
Spacer (.020)
Spacer (.025)
Spacer (.032)
Spacer (.050)
7 5630279 3 Weight, Shift, 16
8 7512266 3 Bolt, Shoulder
9 7541906 3 Nut, FLEXLOC
10 3576504 1 Bearing, Moveable (1/2I)
11 5020422 3 Pin, Roller
12 7041157 1 Spring, Clutch
13 3576510 1 Cover, Bearing
14 1321632 1 Asm., Drive Clutch, ATV-08
(Incl. All Less 7,12)
2/00
