The Ultimate Edge™ Soundcard Users Guide 21
3.3.4. Mixer Tab
Mixer controls allow you to select and control playback and recording input sources.
3.3.4.1. Playback source controls
You can individually mute or un-mute as many playback sources as you wish.
Volume sliders set the playback level for each source.
Balance sliders adjust the relative left and right output levels for each stereo source. Balance
sliders should normally be left in the center, which is the default position. Right-click any of the
balance sliders to center it.
Depending on the number of available playback sources in your PC, the number of horizontal and
vertical slider may vary, and a scrollbar may or may not be present. The viewing area on the
Mixer Tab displays controls for a maximum of four playback sources at one time. Use the
Playback Source Scrollbar (if present) to reveal more source controls. See Figure 14.
Figure 14
When playing audio CD’s using the CD ROM driver of the PC, one should enable the digital audio
extraction in the system device manager. If you need more information refer to the
Troubleshooting section in Appendix D of this document.
NOTE: CD In playback/recording volume is controlled from the CD/Video slider under recording
tab. CD Player slider under playback tab doesn’t control anything.
3.3.4.2. Recording Source Control
The Ultimate Edge soundcard allows you to record sounds and music from multiple input sources.
Select the “mixer” tab, go to the bottom of the panel and click on the “recording” tab. This panel
enables you to select and control recording sources.
