Specifications
This page provides the specifications for the basic model CF-51PF66EBM. The model number is different according to
the unit configuration.
z
To check the model number:
Check the bottom of the computer or the box the computer came in at the time of purchase.
z To check CPU speed, memory size and the hard disk drive (HDD) size:
Run the Setup Utility (Î
Reference Manual “Setup Utility”) and select [Information] menu.
[CPU Speed]: CPU speed, [System Memory]: Memory size, [Primary Master]: Hard disk drive size
„ Main Specifications
Model No. CF-51PF66EBM
CPU
Intel
®
Core™ Duo Processor T2500 (2 GHz, 2 MB L2 cache, 667 MHz FSB)
Chipset Intel ® 945PM
Memory *1*2 2048 MB (4096 MB *3 Max.)
Video Memory *1 128 MB
Hard Disk Drive *4 80 GB
Floppy Disk Drive *5 720 KB/1.44 MB (two-mode)
CD/DVD Drive Î page 28
Display Method 15.0 UXGA type (TFT)
Internal LCD *6 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1600 × 1200 dots)
External Display *7 65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 1024 dots/1600 × 1200 dots/
2048 × 1536 dots)
Wireless LAN *8 Î page 28
Bluetooth *9 Version 2.0+EDR
LAN IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
Modem Data: 56 kbps (V.92) FAX: 14.4 kbps
Sound
WAVE and MIDI playback, Stereo speaker, Intel ® High Definition Audio subsystem support
Security Chip
TPM (TCG V1.2 compliant)
*10
Card
Slot PC Card Type I or Type II x 2, or Type III x 1 (3.3 V: 400 mA, 5 V: 400 mA)
SD Memory
Card
*11
x 1 (Data transfer rate = 8 MB per second *12 )
Smart Card
*13 x 1
RAM Module Slot 200-pin, SO-DIMM, PC2-4200 DDR2 SDRAM
Interface USB port (4-pin, USB 2.0) x 4, Serial Port (Dsub 9-pin male), Modem port (RJ-11), LAN port (RJ-45),
External display port (Mini Dsub 15-pin female), External keyboard/ Mouse port (Mini DIN 6-pin female),
Expansion Bus Connector (Dedicated 100-pin female), IEEE1394a Interface Connector (4-pin
× 1),
Microphone Jack (Miniature jack, 3.5 DIA, Stereo), Headphone Jack (Miniature jack, 3.5 DIA, Impedance
32
Ω , Output Power 4 mW × 2, Stereo)
Keyboard / Pointing Device 87 keys / Touch Pad
Power Supply
AC adaptor or Battery pack
AC Adaptor
*14 Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 15.6 V DC, 8.0 A
