Page - 4 - Installation Manual
Features: The PRC-LA allows tilt and pivot adjustments ±15° from center, 360° side-to-side swivel, and cable access. The
AST-2446 allows height adjustment from 24 to 46 inches. Plus it also features two cable access openings.
PRC-LA
M6 x 6mm
Set Screw
Coupler
Swivel Lock
Keyhole Mount
Opening
VESA 75 x 100
Mounting Points
Keyhole Mount
Opening
Ceiling Plate Ceiling Plate
Cable Access
Opening Cable Access
Opening
Lower Tube
The AST-2446 may be substituted for a custom pre-cut length of threaded 1-1/2” NPT pipe.
