Pioneer HOME CINEMA SYSTEMS - Manual (Page 61)

61
Features and Specifications
See page 65 for rear panels of Digital Home Cinema Systems.
Digital Home Cinema
Systems Features - 2
TERMINALS
Digital Input
Coaxial
Optical
Digital Output (Optical)
Audio (TUNER Included)/Video Inputs
Audio/Video Output
S-Video Input/Output
S2 Compatibility
SATELLITE AND SUBWOOFER SPEAKER SYSTEM
Magnetically Shielded (Satellite)
Magnetically Shielded (Subwoofer)
N
S-D
V88
N
S-D
V77
DC
S-1
00
HTD-5
• • •
• • •
• •
AUX x 3 / - AUX x 3 / - TV x 1 / AUX x 1 TV x 1 / AUX x 1
for system cable / AUX x 1 for system cable / AUX x 1 AUX OUT x 1 AUX OUT x 1
- / • - / • - / • - / •
• • • •
• • •
• •
Digital Home Cinema
Systems Specifications
SYSTEM
Cable length
DVD Tuner—Display
DVD Tuner—Subwoofer
Display Unit
Dimensions
Weight
Remote Control Unit
Dimensions (W x H x D)
Weight
Power Requirements
Power Consumption In Use / Standby
Dimensions (W x H x D)
Weight
AMPLIFIER SECTION
DIN Continuous Power Output (8 Ω)
Front (1 kHz, 1 % THD)
Centre (1 kHz, 1 % THD)
Rear (1 kHz, 1 % THD)
Subwoofer (100 Hz, 1 % THD)
RMS Power Output (8 Ω)
Front (1 kHz, 1 % THD)
Centre (1 kHz, 1 % THD)
Rear (1 kHz, 1 % THD)
Subwoofer (100 Hz, 1 % THD)
CD/DVD PLAYER SECTION
S/N Ratio (Audio)
Dynamic Range
Distortion
Frequency Response
48 kHz Sampling
96 kHz Sampling
SPEAKER SECTION
Front Satellite
Impedance
Frequency Range
Maximum Input Power
Sensitivity (1 m/W)
Dimensions (W x H x D)
Weight
Centre Satellite
Impedance
Frequency Range
Maximum Input Power
Sensitivity (1 m/W)
Dimensions (W x H x D)
Weight
Rear Satellite
Impedance
Frequency Range
Maximum Input Power
Sensitivity (1 m/W)
Dimensions (W x H x D)
Weight
Subwoofer
Impedance
Frequency Range
Maximum Input Power
Sensitivity (1 m/W)
Dimensions (W x H x D)
Weight
N
S-D
V88
N
S-D
V77
DC
S-1
00
HTD-5
1.5 m 1.5 m
5 m 5 m
206 x 65 x 50 mm 206 x 65 x 50 mm
0.2 kg 0.2 kg
55 x 26 x 190 mm 55 x 26 x 190 mm 58 x 190 x 23.2 mm 59 x 190 x 23 mm
0.08 kg (without battery) 0.08 kg (without battery) 0.09 kg (without battery) 0.09 kg (without battery)
220 - 230 V/50 - 60 Hz 220 - 230 V/50 - 60 Hz 220 - 240 V/50 - 60 Hz 220 - 230 V/50 - 60 Hz
166 W / 1 W 166 W / 1 W 118 W / 1 W 136 W / 1 W
220 x 65 x 317 mm 220 x 65 x 317 mm 360 x 332 x 75 mm 420 x 150 x 411.6 mm
2.5 kg 2.5 kg 5.1 kg 9.8 kg
30 W per channel (8 Ω, 1 % THD) 30 W per channel (8 Ω, 1 % THD) 18 W per channel (6 Ω, 1 % THD) 60 W per channel (8 Ω, 1 % THD)
30 W (8 Ω, 1 % THD) 30 W (8 Ω, 1 % THD) 18 W (6 Ω, 1 % THD) 20 W (8 Ω, 1 % THD)
30 W per channel (8 Ω, 1 % THD) 30 W per channel (8 Ω, 1 % THD) 18 W per channel (6 Ω, 1 % THD) 20 W per channel (8 Ω, 1 % THD)
50 W (4 Ω, 1 % THD) 50 W (4 Ω, 1 % THD) 18 W (6 Ω, 1 % THD) 60 W (8 Ω, 1 % THD)
25 W per channel (6 Ω, 10 % THD) 80 W per channel (8 Ω, 10 % THD)
25 W (6 Ω, 10 % THD) 30 W (8 Ω, 10 % THD)
25 W per channel (6 Ω, 10 % THD) 30 W per channel (8 Ω, 10 % THD)
25 W (6 Ω, 10 % THD) 80 W (8 Ω, 10 % THD)
100 dB 100 dB 95 dB 115 dB
97 dB 97 dB 95 dB 100 dB
0.004 % 0.004 % 0.004 % 0.004 %
4 — 22,000 Hz 4 — 22,000 Hz 4 — 22,000 Hz 4 — 22,000 Hz
4 — 44,000 Hz 4 — 44,000 Hz 4 — 44,000 Hz 4 — 44,000 Hz
8.7 cm 8.7 cm 8.7 cm 10 cm woofer, 5.2 cm tweeter
8 Ω 8 Ω 6 Ω 8 Ω
100 — 20,000 Hz 100 — 20,000 Hz 100 — 20,000 Hz 50 — 20,000 Hz
40 W 40 W 40 W 100 W
86 dB 86 dB 84 dB 85.5 dB
110 x 154 x 78 mm 110 x 154 x 78 mm 110 x 155 x 76 mm 150 x 270 x 178 mm
0.81 kg 0.81 kg 0.75 kg 2.0 kg
8.7 cm 8.7 cm 8.7 cm 8.7 cm
8 Ω 8 Ω 6 Ω 8 Ω
100 — 20,000 Hz 100 — 20,000 Hz 100 — 20,000 Hz 80 — 20,000 Hz
40 W 40 W 40 W 34 W
85 dB 85 dB 84 dB 86.5 dB
210 x 110 x 78 mm 210 x 110 x 78 mm 200 x 110 x 76 mm 370 x 120 x 130 mm
0.92 kg 0.92 kg 0.8 kg 1.8 kg
8.7 cm 8.7 cm 8.7 cm 8.7 cm
8 Ω 8 Ω 6 Ω 8 Ω
100 — 20,000 Hz 100 — 20,000 Hz 100 — 20,000 Hz 110 — 20,000 Hz
40 W 40 W 40 W 33 W
86 dB 86 dB 84 dB 86 dB
110 x 154 x 78 mm 110 x 154 x 78 mm 110 x 155 x 76 mm 115 x 150 x 96 mm
0.81 kg 0.81 kg 0.75 kg 0.8 kg
16 cm 16 cm 16 cm 16 cm
4 Ω 4 Ω 6 Ω 8 Ω
31 — 300 Hz 31 — 300 Hz 30 — 300 Hz 30 — 200 Hz
65 W 65 W 50 W 100 W
81 dB 81 dB 78 dB 82 dB
190 x 420 x 420 mm 190 x 420 x 420 mm 190 x 282 x 267 mm 190 x 360 x 327 mm
14.2 kg 14.2 kg 3.8 kg 4.8 kg
