LA1710R, LA1710RTR and LA1710RTC User’s Guide ( 020-0320-01 Rev. A)
25
Touch Screen Driver Installation
Driver Installation for LA1710RTR:
Resistive Touch Screen with USB Connection
Please note: These monitors are Microsoft Windows® HID (Human Interface
Device) compatible. No additional software driver is required for general op-
eration of the touch screen.
A special calibration tool can be installed for improved touch position ac-
curacy. See Optional MicroTouch
TM USB HID Calibration Tool version 7.00
Installation Process.
Optional Driver MicroTouch TM USB HID Calibration Tool Version
7.00 Installation Process for LA1170RTR: Resistive Touch Screen
with USB Connection
Please note: These monitors are Microsoft HID (Human Interface Device)
compatible. The calibration driver is not required for general operation of the
touch screen.
This calibration tool is for optimization of touch performance for the touch
screen to meet the 1% TPE accuracy specifi cation.
The following Microsoft Windows® operating systems are supported by this
software driver: Microsoft Windows® 98SE, Me, 2000, and XP.
1. Be sure that the USB cable is not connected to the PC.
2. Open the CD-Rom.
3. Click the “LA1500RTR, LA1710RTR, PT1500MU / 1700MU Calibration
Option” link.
4. Click “I accept” when the software license screen appears.
5. Follow the step-by-step instructions.
6. Reconnect the USB cable to the computer prior to use.
7. If the touch screen driver does not automatically load, restart the computer
operating system.
Please read “Readme.txt” located in the unzipped fi le folder for
additional information and assistance.
