Touchscreen and Peripherals Driver Installation

Drivers for all supported operating systems are contained on the Preh Install Disk. To install

drivers, follow the procedures below as appropriate.

Touchscreen support is provided for Windows 98/Me/NT/2000/XP, DOS and Linux (kernels

4.2.18 and above).

The MSR and Customer Display, which are USB devices, are currently supported under

Windows platforms only. Support for Linux will be provided in the future. Contact Preh

TechSupport for further information.

Windows 98/Me/NT/2000/XP Installation:

If you are using a USB data interface, disconnect it from the computer before proceeding.

Connect the touchscreen cable if using a serial interface (MCI 15 only). Insert the disk in

your drive. If AutoRun does not start the installation, double click the “Setup” program in

the CDROM folder.

Follow the instructions pertaining to your particular product configuration, and check the

appropriate boxes in the “Select Features” page to install drivers for the peripherals you

have. The POS demo program may be installed now or at any time in the future.

If the installation program does not restart your computer, shut down, connect the USB

cable, if used, and restart.

After restart, the touchscreen controller and other USB devices, if present (the MSR and

Customer Display), will be found by Windows and the drivers automatically installed for

them.

Find the Preh MCI Touch Monitor Settings icon on the desktop or in Control Panel and use

the features under the appropriate tabs to configure the operation of the touchscreen for

your application, and if necessary, to calibrate the touchscreen to the display image.

The MSR, if present, is configured for keyboard emulation by default. It should work

identically to keyboard wedge readers in all applications. Contact Preh TechSupport at

[email protected] (Americas only) or [email protected] if this format is

not suitable for your application.

The Customer Display, while hardware interfaced as a USB device, is equivalent to a

serial display for programming purposes. Contact Preh Technical Support for programming

information on this device.

DOS Installation:

See specific procedures in DOS section of disk.

Linux Installation:

See specific procedures in Linux section of disk.

Kernels 2.4.18 and above (corresponding to RedHat Linux versions 8 and 9) are

supported.

Source code is available on request.

For additional information contact Preh at [email protected] (Americas only) or

[email protected]

MCI 15 Specifications

Monitor Part Numbers

MCI 15
MCI 15M
MCI 15MD

Display

15” Color AMTFT LCD

Color

Black

Touchscreen Technology

5-wire resistive

Active Screen Dimensions

Horizontal

11.9” (304 mm)

Vertical

8.9” (228 mm)

Monitor Dimensions

With Stand

Height

13.9” (35.22 cm)

Width

15.5” (39.37 cm)

Depth

8.25” (20.95 cm)

Without Stand

Height

12.9” (32.68 cm)

Width

15.5” (39.37 cm)

Depth

2.5” (6.36 cm)

Weight

MCI 15M

Actual

15 lb / 6.8 kg

Shipping

21 lb / 9.5 kg

Brightness

LCD

250 nit

With touchscreen

200 nit

Resolution

Native

1024 x 768 at 60, 70, or 75 Hz

Supported

800 x 600 at 56, 60,72, and 75 Hz
720 x 400 at 70 Hz; 720 x 350 at 70 Hz
640 x 480 at 60, 72, and 75 Hz

Viewing Angle

Horizontal

120° Total (60° left/right)

Vertical

105° Total (60° up/45° down)

Contrast Ratio

400 to 1

Scanning Frequency

Horizontal

31.5 - 60 kHz

Vertical

56 - 75 Hz

Video Input

Analog RGB (VGA)
Analog RGB with sync on green

Video Bandwidth

80 MHz

Input Video Format

VGA/SVGA/XGA analog

Power Supply Voltages

Internal DC supply

AC input 100-240VAC/50-60 Hz

Power Dissipation

30 W max

Temperature

Operating

0°C to 40°C

Storage

-30°C to 60°C

Humidity

Operating

20% to 80% non-condensing

Storage

5% to 90% non-condensing
