YPbPr/YCbCr input connection
If the signal/source is the equipment with YPbPr/YCbCr output terminals, we recommend you to use
the YPbPr/YCbCr terminals on the equipment. Please connect it with the YPbPr/YCbCr input terminals
on the TV set for better picture quality. And connect the audio outputs of it with the corresponding
audio input terminals on the TV set.
If you select YPbPr/YCbCr signal, please set the input signal source of the LCD-TV to YPbPr mode.
DVD, STB etc.
White (audio, L)
Red (audio, R/Pr)
Green (Y)
Blue (Pb)
