Installation
11
AV OUT connection
How to connect:
Connect the video/audio output terminals on the TV set to the signal input terminals of the VCR
equipment or the video/audio input terminals on other TV set through video/audio cable.
Connect the audio output terminals on the TV set to the Audio amplifier through audio cable.
How to record the TV program:
1. Turn on the LCD TV and select program.
2. Turn on the VCR and insert the tape.
3. Press the RECORD button to begin recording.
How to enjoy high quality sound by Audio amplifier:
1. Turn the volume of the Audio amplifier to minimum.
2. Turn on the LCD TV and select program.
3. Turn on the power amplifier and adjust the volume as favourite.
To audio inputs
Audio amplifier
To video output
To video input
VCR
Yellow (video)
White (audio, L)
Red (audio, R)
W
Y
R
AUDIO
W
Y
R
W
Y
R
W
R
To audio input
To audio outputs
