OPERATION
EATON Powerware ® Energy Management System (EMS) Upgrade Kit User’s Guide
S
164201724 Rev 1 www.powerware.com 41
Table 7. Panel Meters
Screen Label Meters Displayed
Panel
(first screen) ALM
%LOAD
Vavg
Imax Alarm status (W for warnings, A for critical alarms)
Ratio (in percent) of present load compared to maximum
Average voltage
Phase with highest current
Panel
(second screen) V1, V2, V3
I1, I2, I3 Voltage per phase
Current per phase
Panel
(third screen) I1%, I2%, I3%
KW
KVA
PF Ratio (in percent) of present current compared to maximum
Total kW of panel breakers
Total kVA of panel breakers
Power factor
Panel
(fourth screen) #BRKS
KWH/m
KWH/y
KWHt Number of breakers
Kilowatt hours per month
Kilowatt hours per year
Total kilowatt hours
Panel*
(fifth screen) MAX V
MAX I Maximum voltage logged
Maximum current logged
* To reset the panel statistics (fifth screen) to zero, select RESET.
Table 8. Breaker Meters
Screen Label Meters Displayed
Panel X Breaker Meters
(first screen) ALM
CURR%
PHASE
Irms
RTNG Alarm status
Ratio (in percent) of present current compared to breaker rating
Phase assignment
Current (RMS value)
Breaker rating
Panel X Breaker Meters
(second screen) W
VA
PF
WARN
OVER Average W
Average VA
Average power factor
Threshold load (in percent) at which a warning alarm is logged
Threshold load (in percent) at which an overage alarm is logged
Panel X Breaker Meters
(third screen) KWH/m
KWH/y
KWHt Kilowatt hours per month
Kilowatt hours per year
Total kilowatt hours
Panel X Breaker Meters
(fourth screen) Imax
Wmax
VAmax
PFmin Maximum current logged
Maximum W logged
Maximum VA logged
Minimum power factor logged
