Pride Mobility 1107 User Manual
Page 15
Jazzy 1107
www.pridemobility.com
15
I I I . Y O U R P O W E R C H A I R
THE JAZZY 1107
The Jazzy has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat assembly
includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake assemblies, two drive
wheels, two anti-tip wheels, two caster wheels, two battery boxes, and wiring harnesses. See figures 5, 6, and 7.
Figure 5. The Jazzy 1107
SEATBACK
ARMRESTS
CONTROLLER
ANTI-TIP WHEELS
DRIVE WHEEL
CASTER WHEEL
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOT RIGGING (FOOT
PLATFORM SHOWN)
SEAT BASE
SEATBACK RELEASE LEVER
CONTROLLER
HARNESS
