- 7 -
Parts Introduction
Right Side Of The Panel
1. Earphone volume adjusting knob
-Used to adjust the earphone and speaker volume.
2. Earphone jack
-HI-FI earphone output, when connecting this jack, speaker volume is turned off.
3. Audio output/input jack
4. Video output/input jack
5. Switch position between AV ‘IN’ and AV ‘OUT’
-Switch to IN, then the player is in audio and video input mode.
-Switch to OUT, then the player is in normal playback mode.
6. Direct current 12V input jack
Left Side Of The Panel
7. Earphone jack
