Planar Touch Monitor LX1200TI - Manual (Page 27)

LX1200TI User’s Guide (020-0512-01A)
27
Addendum A
Planar Softkey Use
The Planar LX1200TI has built in programmable function buttons. This docu-
ment is to guide the user on the use and installation of the softkey software.
The Function buttons are mapped out of the box as:
BUTTON INITIAL KEY
MAPPING
DEFAULT SOFTKEY
MAPPING
POSSIBLE KEY
MAPPING
E F18 F11 Alt+F11
1 F13 F1 Launch Program
2 F14 F2 Ctnl+Alt+2
3 F15 F3 Past Text
4 F16 F4 Launch IE7 to an address
5 F17 F5 Open a Folder
The Planar softkey software will allow the user to remap those keys to any
other single keys, combination of keys, or launch a program from the buttons
on the front of the LX1200TI monitor.
Softkey Install Guide
1. Install the Planar Softkey software from the CD by clicking on the Planar
Softkey
Icon.
