CTM-MS1

Page14

Installation Manual

Step 3. Tilt the flat panel and secure the two (2) M6 x 12mm safety knobs to each of the mounting brackets.

To remove the display from the wall simply extend the display to its maximum tilt range, remove the two 6 (mm)
safety knurl knobs push the flat panel back to it’s flat position, loosen or remove the two (2) M6 x 30 lateral shift
screws and lift the unit of the wall.
