Panasonic DMC-FZ20GN - Manual (Page 96)

Connecting to a PC or Printer
96
Connecting to a PC
• If you use Windows 98/98SE, install the
USB driver and then connect it to the
computer.
• When using Windows Me/2000/XP, Mac
OS 9.x and Mac OS X, you do not have to
install the USB driver.
A: USB connection cable (supplied)
B: AC adaptor (DMW-CAC1; optional)
1 Turn the camera on and set the
[USB MODE] according to the OS
you use.
• Set to [PC] or [PictBridge (PTP)]. Refer
to “Before Connecting with USB
Connection Cable” on page 94.
• If [USB MODE] is set to [PictBridge
(PTP)] while Windows XP or Mac OS X
is used, it is connected as PTP.
2 Connect the camera to a PC via
the USB connection cable A
(supplied).
• Connect the USB connection cable with
the [ ] mark facing you.
• Hold C and then insert or pull the USB
connection cable straight.
Depending on the USB mode setting, the
indications on the screen may vary. Refer
to page 97.
