Page 18

Preparation
18
Attaching the Lens Hood
In bright sunlight or backlight, the lens hood
will minimise lens flare and ghosting.
The lens hood cuts off excess lighting and
improves the picture quality.
• Check that the camera is turned off and
that the lens is retracted.
• Close the flash.
1 1 Detach the lens ring.
2 Attach the lens hood adaptor.
2 Attach the lens hood.
1 Place the camera upside down.
2 Catch the hook on the lens
hood adaptor.
3 Push the lens hood.
4 Align the marks as illustrated.
5 Tighten the screw.
• Check if the screw is loose and then
attach the lens hood.
• Do not tighten the screw too much.
4
1
3
2
5
FZ20-GN.book 18 ページ 2004年8月9日 月曜日 午後5時51分
