Specifications
AMPLIFIER SECTION
RMS Output Power: Dolby Digital Mode
Front Ch
Surround Ch
Center Ch
Subwoofer Ch
125 W per channel (3
≠), 1 kHz, 10 % THD
125 W per channel (3
≠), 1 kHz, 10 % THD
250 W per channel (6
≠), 1 kHz, 10 % THD
250 W per channel (6
≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
1000 W
FTC Output Power: Dolby Digital Mode
Front Ch
Surround Ch
Center Ch
Subwoofer Ch
63 W per channel (3
≠), 120 Hz to 20 kHz, 1 % THD
48 W per channel (3
≠), 120 Hz to 20 kHz, 1 % THD
106 W per channel (6
≠), 120 Hz to 20 kHz, 1 % THD
100 W per channel (6
≠), 45 Hz to 120 Hz, 1 % THD
Total FTC Dolby Digital mode power
428 W
FM/AM TUNER, TERMINALS SECTION
Preset Memory
FM 30 stations
AM 30 stations
Frequency Modulation (FM)
Frequency range
87.9 MHz to 107.9 MHz (200-kHz step)
87.5 MHz to 108.0 MHz (100-kHz step)
Antenna terminals
75
≠ (unbalanced)
Amplitude Modulation (AM)
Frequency range
520 kHz to 1710 kHz (10-kHz step)
Digital audio input
Optical digital input
Sampling frequency
Optical terminal
32 kHz, 44.1 kHz, 48 kHz
Phone jack
Terminal
Stereo, 3.5 mm (
1
/
8
z) jack
[PT670] Calibration Mic
Sensitivity
100 mV, 1.4 k
≠
Terminal
Mono, 3.5 mm (
1
/
8
z) jack
DISC SECTION
Discs played [8 cm (3
z) or 12 cm (5z)]
(1) DVD (DVD-Video)
(2) DVD-RAM (DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(3) DVD-R (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(4) DVD-R DL (DVD-Video, DVD-VR)
(5) DVD-RW (DVD-Video, DVD-VR, MP3
§2, 5
, JPEG
§4, 5
)
(6)
iR/iRW (Video)
(7)
iR DL (Video)
(8) CD, CD-R/RW (CD-DA, Video CD, SVCD
§1
, MP3
§2, 5
, WMA
§3, 5
,
JPEG
§4, 5
)
§1
Conforming to IEC62107
§2
MPEG-1 Layer 3, MPEG-2 Layer 3
§3
Windows Media Audio Ver.9.0 L3
Not compatible with Multiple Bit Rate (MBR)
§4
Exif Ver 2.1 JPEG Baseline files
Picture resolution: between 160
k120 and 6144k4096 pixels (Sub
sampling is 4:0:0, 4:2:0, 4:2:2 or 4:4:4). Extremely long and narrow
pictures may not be displayed.
§5
The total combined maximum number of recognizable audio and
picture contents and groups: 4000 audio and picture contents and
255 groups. (Excluding Root folder)
Pick up
Wavelength (DVD/CD)
655/785 nm
Laser power (DVD/CD)
[U.S.A.]
[Others]
CLASS II/CLASS I
CLASS 1/CLASS 1M
Audio output (Disc)
Number of channels
5.1 ch (FL, FR, C, SL, SR, SW)
VIDEO SECTION
Video system
NTSC
Composite video output
Output level
Terminal
1 Vp-p (75
≠)
Pin jack (1 system)
Component video output
Y output level
P
B
output level
P
R
output level
Terminal
1 Vp-p (75
≠)
0.7 Vp-p (75
≠)
0.7 Vp-p (75
≠)
Pin jack (Y: green, P
B
: blue, P
R
: red) (1 system)
HDMI AV output
Terminal
19-pin type A connector
HDAVI Control
This unit supports “HDAVI Control 4” function.
SPEAKER SECTION
[Front\speakers\SB-HF770]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 3
≠
Full range
6.5 cm (2
1
/
2
z) Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
tHtD)
Mass [Weight]
Full assembly with stand base
Dimensions (W
tHtD) max
Dimensions (W
tHtD) min
Mass [Weight]
125 W
§6
(Max)
79 dB/W (1.0 m)
80 Hz to 25 kHz (
j16 dB)
90 Hz to 22 kHz (
j10 dB)
100 mm
k530 mmk78 mm
(3
15
/
16
zk20
7
/
8
zk3
1
/
16
z)
0.92 kg (2.2 lbs)
255 mm
k1020 mmk255 mm
(10
1
/
16
zk40
3
/
16
zk10
1
/
16
z)
255 mm
k550 mmk255 mm
(10
1
/
16
zk21
21
/
32
zk10
1
/
16
z)
2.3 kg (5.1 lbs)
[Surround\speakers\SB-HS470]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 3
≠
Full range
6.5 cm (2
1
/
2
z) Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
tHtD)
Mass [Weight]
125 W
§6
(Max)
79 dB/W (1.0 m)
100 Hz to 25 kHz (
j16 dB)
120 Hz to 22 kHz (
j10 dB)
92 mm
k128 mmk81 mm
(3
5
/
8
zk5
1
/
32
zk3
3
/
16
z)
0.47 kg (1.1 lbs)
[Center\speaker\SB-HC470]
Type
Speaker unit(s)
2 way, 2 speaker system (Bass reflex)
Impedance 6
≠
1. Woofer
2. Full range
6.5 cm (2
1
/
2
z) Cone type
6.5 cm (2
1
/
2
z) Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
tHtD)
Mass [Weight]
250 W
§6
(Max)
81 dB/W (1.0 m)
82 Hz to 25 kHz (
j16 dB)
99 Hz to 22 kHz (
j10 dB)
250 mm
k94.5 mmk81 mm
(9
27
/
32
zk3
3
/
4
zk3
3
/
16
z)
1.15 kg (2.6 lbs)
[Subwoofer\SB-HW460]
Type
Speaker unit(s)
1 way, 1 speaker system (Bass reflex)
Impedance 6
≠
Woofer
16 cm (6
1
/
2
z) Cone type
Input power (IEC)
Output sound pressure
Frequency range
Dimensions (W
tHtD)
Mass [Weight]
250 W (Max)
81 dB/W (1.0 m)
31 Hz to 220 Hz (
j16 dB)
37 Hz to 180 Hz (
j10 dB)
153 mm
k415 mmk257 mm
(6
1
/
32
zk16
11
/
32
zk10
1
/
8
z)
3.6 kg (7.9 lbs)
