- 45 (E) -
Menu item setting
W ATW Speed Setting
[ATW Speed: Slow 2, Slow 1, Mid, Fast 1, Fast 2]
ATW Speed can be set.
X Black Level Setting [Pedestal: –150 to +150]
The black level (pedestal) of the luminance (Y) signal can
be set. Used in adjusting the black levels of two or more
cameras.
Y Painting Setting
[Painting: R Gain, B Gain, R Pedestal, B Pedestal:
–150 to +150]
R Gain, B Gain:
Fine adjustment of the white balance can be made
after AWC setting when AWC A or AWC B is
selected in White Balance Setting. In case of using
the RCU (RCB), use the R/B gain controls for this
purpose. The set value returns to ±0 after AWC
setting in using the camera alone.
R Pedestal, B Pedestal:
Fine adjustment of the black balance can be made
after ABC setting.
In case of using the RCU (RCB), use the R/B
pedestal controls for this purpose. The set value
returns to ±0 after ABC setting in using the camera
alone.
R/B gain
control
R/B pedestal
control
RCU (RCB)
