8
Chapter 3 Technical Information
Specifications
LCD Panel
Size 17" (43 cm)
Display Type Active matrix color TFT LCD
Resolution 1280 x 1024
Display Dot 1280 x (RGB) x 1024
Display Area (mm) 337.92 x 270.336 (H x V)
Display Color 262K
Brightness 260 cd/m 2 (typical), 200 cd/m 2 (min.)
Contrast Ratio 450:1 (typical)
Response Time Ta=25°C Tr+Tf=12ms
Lamp Voltage 650 Vrms (typical)
Lamp Current 7.0 mA rms. (typical)
Viewing Angle
Vertical: -60° ~ +75°
Horizontal: -75° ~ +75°
Display Colors 16M (6 bit + FRC)
Video
Input Signal
Input Impedance
Polarity
Amplitude
Multi-mode Supported
Analog RGB 0.7Vp-p/ Digital TMDS
75 Ohm ± 2%
Positive, Negative
0 - 0.7 ± 0.05 Vp
Horizontal Frequency: 24 ~ 80 KHz
Vertical Frequency: 49 ~ 75 Hz
Control
Power switch
(hard and soft types) On/Off switch with LED indicator
OSD
Brightness
Contrast
Horizontal Position
Vertical Position
Phase
Clock
Display Mode Setup
OSD Format
Digital
Digital
Digital
Digital
Digital
Digital
Use EEPROM to save settings in memory
26 characters x 15 rows
Power Management
Mode Power Consumption* AC Input LED Color
On 48W maximum 240 VAC Green
Off 3W maximum 240 VAC Yellow
Soft switch off 3W maximum 240 VAC Dark
Disconnected 3W maximum 240 VAC
Yellow: Standby, Suspend, Off
Dark: DC Power off
Hard switch off 0W 240 VAC Dark
* Meeting VESA DPMS requirements measured from AC Input end of AC power cord.
Sync Input
Signal
Separate TTL compatible horizontal and vertical synchronization
Digital TMDS
Polarity Positive and negative
