9

Polarity

Positive and negative

Plug & Play

Supports VESA DDC2B functions

External Connection

Power Input (AC input)

AC socket

Video Cable

1.8M with 15-pin D-sub connector, 1.8M with 24-pin DVI-D

Environment

Operating Condition:

Temperature

5°C to 40°C/41°F to 104°F

Relative Humidity

20% to 80%

Storage Condition:

Temperature

-20°C to 60° C/-4°F to140° F

Relative Humidity

5% to 85%

Power Supply (AC Input)

Input Voltage

Single phase, 100 ~ 240VAC, 50 / 60 Hz

Input Current 1.2 A

maximum

Size and Weight

Dimensions

374 (W) x 394.5 (H) x 204 (D) mm

Net Weight

5

± 0.3 kg

Gross Weight

7

± 0.3 kg

Pin Assignment

Signal

Signal

PIN

Description

PIN

Description

1

5

6

10

11

15

1
2
3
4
5
6
7
8

Red
Green
Blue
Digital GND
Digital GND
Red Rtn
Green Rtn
Blue Rtn

9

10
11
12
13
14
15

+5V
Hot Plug Detect
NC
SDA
H. Sync.
V. Sync.
SCL

For Digital DVI-D connector

Signal

Signal

Signal

PIN

Description

PIN

Description

PIN

Description

1

RX2-

10

RX1+

19

Shield for TMDS Channel 0

2

RX2+

11 Shield for TMDS Channel 1 20

NC

3

Shield for TMDS Channel 2 12

NC

21

NC

4

NC

13

NC

22

Shield for TMDS Channel clock

5

NC

14

+5V

23

RXC+

6

SCL

15

Hot Plug Detect

24

RXC-

7

SDA

16

HPD

C5

NC

8

NC

17

RX0-

C6

NC

9

RX1-

18

RX0+
