32
WAP Settings
Use the table below to record your WAP settings.
Item Current Setting
Server Name
Dial Number
Call Type
Login Name
Password
IP Address
IP Port
Homepage URL
Linger Time
Specifications
Phone (Including Battery)*
Type
GSM 900 Class 4
GSM1800 Class 1
GSM1900 Class 1
Temperature Range
Charging
Storage +5°C - +35°C
-20°C - +60°C
WAP WAP 1.2.1
Weight Max 65 g
Dimensions
Height x Width x Depth
77 x 43 x 16.9mm (excluding antenna)
Supply Voltage 720 mAh Li-ion
Standby Time
Talk Time 78.3 Hrs ~ 230 Hrs
1.6 Hrs ~ 7.9 Hrs
Charging Time (Phone off) Less than 120 mins (Travel Charger)
Antenna External Stub Antenna
SIM Type 3V Plug-in only SIM
Note: Charge time will be longer when the phone is turned on. Battery life is
affected by the network being used, SIM card usage, and the condition of the
battery.
