11
Power Management
Mode Power Consumption* AC Input LED Color
DPM ON 48W maximum 240 VAC GREEN
DPM OFF 2W maximum 240 VAC Yellow
DC switch off 1W maximum 240 VAC Dark
Disconnected 2W maximum 240 VAC Dark
Meeting VESA DPM requirements measured from AC Input end of AC power cord.
Sync Input Analogue
Signal Separate TTL compatible horizontal and vertical
synchronization
Polarity Positive and negative
Plug & Play Supports VESA DDC2B functions
External Connection
Power Input (AC input) AC socket
Video Cable 15-pin D-sub connector
Audio Cable Stereo Jack
Environment
Operating Condition:
Storage Condition:
Temperature
Relative
Humidity
Temperature
Relative
Humidity 5°C to 40°C/41°F to 104°F
20% to 80%
-20°C to 60° C/-4°F to140° F
5% to 85%
Power Supply (AC Input)
Input Voltage Single phase, 100 ~ 240VAC, 50 / 60 Hz
Input Current 1.2 A maximum
Size and Weight
Dimensions 367 (W) x 383.4 (H) x 199 (D) mm
Net Weight 3.6
± 0.3 kg
Gross Weight 5.6 ± 0.3 kg
