10

Technical Information

Specifications

LCD Panel

Size

17" (43 cm)

Display Type

Active matrix color TFT LCD

Resolution

1280 x 1024

Display Dot

1280 x (RGB) x 1024

Display Area (mm)

337.92 x 270.336 (H x V)

Display Color

16.2M (RGB 6 bit+FRC)

Lamp Voltage (typical)

650 Vrms

Lamp Current (typical)

7.0 mA rms.

Video

Input Signal
Input Impedance
Polarity
Amplitude
Multi-mode Supported

Analogue RGB 0.7Vp-p
75 Ohm ± 2%
Positive, Negative
0 - 0.7 ± 0.05 Vp
Horizontal Frequency: 30 ~ 80 kHz
Vertical Frequency: 56 ~

75 Hz


Control

Power switch

On/Off switch with LED indicator


Audio

Input 500mVrms
Output 1W+1W

OSD

Brightness
Contrast
Horizontal Position
Vertical Position
Phase
Clock
Display Mode Setup
OSD Format

Digital
Digital
Digital
Digital
Digital
Digital
Use EEPROM to save settings in memory
26 characters x 15 rows
