70
En
Specifications
General
System .. DVD system and Compact Disc digital audio system
Power requirements
DV-S88A ............................................ AC 110 V, 60 Hz
DV-S838A .............................. AC 220-240 V, 50/60 Hz
Power consumption
DV-S88A .............................................................. 29 W
DV-S838A ............................................................ 31 W
Power consumption in standby mode ...... less than 1 W
Weight ................................................................... 9.0 kg
Dimensions ................... 420 (W) x 371 (D) x 130 (H) mm
(Not including protruding cables, etc.)
Operating temperature ............................ +5°C to +35°C
Operating humidity .......... 5% to 85% (no condensation)
S-Video output (2 individual outputs)
Y (luminance) - Output level ........................ 1 Vp-p (75 Ω)
C (color) - Output level ........................ 286 mVp-p (75
Ω)
Jacks .......................................................... S-VIDEO jack
Video output (2 individual outputs)
Output level ................................................ 1 Vp-p (75
Ω)
Jacks ................................................................. RCA jack
Component video output
(Y, P
B
, P
R
)
Output level ......................................... Y: 1.0 Vp-p (75 Ω)
P
B
, P
R
: 0.7 Vp-p (75 Ω)
Jacks ................................................................. RCA jack
D2 video output
Output level ......................................... Y: 1.0 Vp-p (75
Ω)
P
B
, P
R
: 0.7 Vp-p (75 Ω)
Jacks ............................................................... D terminal
Audio output (2 individual outputs)
Output level
During audio output ............. 200 mVrms (1 kHz, –20 dB)
Number of channels ....................................................... 2
Jacks ................................................................. RCA jack
Audio output (5.1 Channel)
Output level
During audio output ............. 200 mVrms (1 kHz, –20 dB)
Number of channels ....................................................... 6
Jacks ................................................................. RCA jack
Digital audio characteristics
Frequency response ... 4 Hz to 88 kHz (DVD fs: 192 kHz)
S/N ratio .............................................. more than 115 dB
Dynamic range .................................... more than 110 dB
Total harmonic distortion .................................... 0.001%
Wow and flutter ............................ Limit of measurement
(±0.001% W. PEAK) or lower
Digital output
Optical digital output ........................... Optical digital jack
Coaxial digital output ......................................... RCA jack
Other terminals
CONTROL IN .......................................... Minijack (3.5 ø)
CONTROL OUT ....................................... Minijack (3.5 ø)
Accessories
Audio cord ...................................................................... 1
Video cord ...................................................................... 1
Power cord ..................................................................... 1
Remote control unit ....................................................... 1
AA (R6P) dry cell batteries ............................................. 2
Operating Instructions ................................................... 1
Note
The specifications and design of this product are subject to
change without notice, due to improvement.
