Planar User’s Manual
7
The Color Mode allows you to adjust the display’s color temperature and individual Red,
Green, or Blue color coordinate settings.
The submenus for each are further described below.
The Display Menu
Pressing the ADJUST key on the monitor activates the Display Menu. Use the ◄FUNCTION► select buttons to
scroll between the submenu items
Contrast: Use the Adjust keys to adjust the difference between the lightest and darkest areas on the
display. The contrast level can range from 0 to 63.
Brightness: Use the Adjust keys to adjust the intensity of the monitor backlight.
Speaker Volume: Use the Adjust to adjust the monitor speaker volume.
Graph/Text: Use the Adjust to change between DOS graphic 640x400 or 720x400. This function is not
used within MS Windows.
Auto Adjust: While the Auto-Adjust sub-menu is selected, press the Adjust key to activate the Auto Adjust
procedure. The Auto Adjust procedure takes approximately 2 seconds to complete. Once finished, the OSD
menu will disappear after a short time-out period.
Exit: Press the Adjust key to exit the Graphic-Control submenu.
Geometric Menu
Pressing the Adjust key on the monitor activates the Geometric submenu. Use the ◄FUNCTION► select buttons to
scroll between the submenu items. You should only use this menu item if the results of the Auto Adjust function are not
satisfactory.
Scale: Press the Adjust key to change to full screen scaling or native resolution.
Clock: Press the Adjust key to stabilize the display clock timing. An improper clock setting will result in
wide vertical bands on the display.
Phase: Press the Adjust key to fine-tune the displayed image. An improper phase adjustment will result in
pixel jitter or display noise.
Horizontal Position: Press the Adjust keys horizontally move the display image to the desired position.
Vertical Position: Press the Adjust keys vertically move the display image to the desired position.
Exit: Press the Adjust key to exit the Geometric submenu.
OSD Adjust Option
Pressing the Adjust key on the monitor activates the OSD Adjust Menu. Use the ◄FUNCTION► select buttons to
scroll between the submenu items.
