Supported Timing
Timing for Model PT1503NT (XGA Resolution)
Item Standards Resolution Dot Clock
(MHz)
Vertical
Scanning
Frequency
(Hz)
Horizontal
Scanning
Frequency
(kHz)
1 NEC PC98 640x400 25.20 70.15 31.50
2 NEC PC98 640x400 21.05 56.42 24.83
3 MAC 13" mode 640x480 30.24 66.67 35.00
4 MAC 16" mode 832x624 57.28 74.55 49.73
5 MAC 17" mode 1024x768 80.00 75.02 60.24
6 VGA 640x350 25.18 70.09 31.47
7 VGA 640x400 25.18 70.09 31.47
8 VGA 640x480 25.18 59.94 31.47
9 VESA 640x480 31.50 72.81 37.86
10 VESA 640x480 31.50 75.00 37.50
11 VESA 800x600 36.00 56.25 35.16
12 SVGA 800x600 40.00 60.32 37.88
13 VESA 800x600 50.00 72.19 48.08
14 VESA 800x600 49.50 75.00 46.88
15 VGA 720x400 28.32 70.09 31.47
16 XGA 1024x768 65.00 60.00 48.36
17 VESA 1024x768 75.00 70.07 56.48
18 VESA 1024x768 78.75 75.03 60.02
19 1024x768 71.64 66.13 53.96
20 SUN 1024x768 64.13 59.98 48.29
21 SUN 1024x768 74.25 70.04 56.59
22 SUN 1024x768 84.38 77.07 62.04
* Once a mode is optimized, there is no need to make any further adjustment as long as the
VGA card remains unchanged.
*Specifications are subject to change without notice.
