Print speed:
83 mm/second
(3.25"/second)
5 meters/minute
(16.25 feet/minute)
Print method:
Color laser
Display:
4-line, 160 x 64 pixel, backlit gray-scale display
Printer processor:
800 / 133 MHz
Media width:
216 mm (8.5")
Print width:
Up to 203 mm (8.00")
Print length:
Up to 381 meters (1250 feet) per 305 mm (12")
roll of self-adhesive label stock (includes face sheet,
adhesive and liner)
Substrate types:
Self-adhesive label stock and approved films
Printing quality
1200 dpi x 1200 dpi
modes:
4800 Color Quality (2400 x 600 dpi)
Ink supplies:
CMYK 4-color printing
(Cyan, Magenta, Yellow, Black)
15,000 page extra high yield cartridges
(Rated according to ISO/IEC 19798 guidelines)
Software:
PTPrint 8.0 RIP Software for Windows
Pantone-approved color support
Easy to use graphical user interface
Input system:
Input roll maximum diameter: 305 mm (12")
Core inside diameter: 76.2 mm (3")
IntelliTorque Tension control system with automatic
paper feed
Maximum input roll weight: 20.4 kg (45 lbs.)
Output system:
Output roll maximum diameter: 305 mm (12")
Core inside diameter: 76.2 mm (3")
IntelliTorque Tension control system
Maximum output roll weight: 20.4 kg (45 lbs.)
Operating system:
Windows XP/Vista
®
, 32-Bit
System
» Intel
®
Pentium
®
-based PC or compatible,
recommendations:
2 GHz processor or higher
» 2 GB RAM or higher
»50 GB or more free hard drive space
» VGA video display of 1024x768 or higher
» Available 100/1000 Ethernet port
Dimensions:
Without bench: 193 cmW x 56 cmH x 56 cmD
(76"W x 22"H x 22"D)
With bench: 193 cmW x 143.8 cmH x 76 cmD
(76"W x 56.625"H x 30"D)
Weight:
Without bench: Approximately 116 kg (256 lbs.)
With bench: Approximately 207 kg (456 lbs.)
Operating
Temperature: 16 to 32°C (60 to 90°F)
environment:
Humidity: 20 to 60% relative humidity
Altitude: 0 – 2000 meters (6,560 feet
)
Power:
110-127 VAC, 50/60 Hz @ 7.5A
220-240 VAC, 50/60 Hz @ 3.5A
Certifications:
CSA, ICES Class A, BSMI Class A, VCCI Class A,
FCC Class A, UL 60950-1, IEC 60320-1, CE Class A,
CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO,
UL AR, CS, TÜV Rh, C-tick mark Class A
Warranty:
One year parts and labor. Usage limitations may apply.
Options:
Extended warranty and on-site service agreements
Matching bench with built-in lockable storage
