Appendix – Planar PL1900 User Manual
Page 20

20
APPENDIX
SPECIFICATIONS
Driving
system
TFT Color LCD
LCD Panel
Size 48.0cm(19")
Pixel pitch
0.294mm( H ) × 0.294mm( V )
Video
R,G,B Analog Interface
Input
Separate
Sync.
H/V TTL
H-Frequency 30kHz – 83kHz (Analog)
V-Frequency 55-75Hz (Analog)
Display Colors
16.2M
Colors
Dot Clock
135MHz
(Analog)
Max. Resolution
1280 × 1024 @75Hz(Analog)
Plug & Play
VESA
DDC2B
TM
EPA ENERGY
STAR
®
ON Mode
≤
37W
OFF Mode
≤
2W
Input Connector
15-pin D-Sub
Input Video Signal
Analog:0.7Vp-p(standard),
75 OHM, Positive
Maximum Screen
Size
Horizontal : 376.32mm
Vertical : 301.056mm
Power Source
100~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5° to 50°C
Storage Temp.: -20° to 60°C
Operating Humidity :
10% to 85%
Dimension
406Ч404Ч207 (W ×H×D)mm
Weight (N. W.)
4.1kg Unit (net)
